PACKAGE HIGHLIGHTS
· Smart-Lok* front differential
· FOX†
2.5 PODIUM QS3†
Piggyback shocks
· Snorkeled engine air intake and CVT
· Belt monitoring system
· 850 W magneto
· 7.6 in. digital display with keypad
· X package graphics / seats
· Can-Am LED signature
· 14 in. aluminum beadlock wheels
· 30 in. ITP Cryptid tires
· Front bumper, half-doors
· Front tow hook
· 4,500 lb (2,041kg) winch with synthetic rope
· HMWPE full skid plate

ENGINE TURBO RR
Type 200 hp, Rotax® ACE (Advanced Combustion Efficiency)
900 cc turbocharged triple-cylinder engine, liquid-cooled
with integrated intercooler, high-performance air filter and
strategically positioned engine air intake
Fuel Delivery System Intelligent Throttle Control (iTC™)
with Electronic Fuel Injection (EFI)
Transmission pDrive primary and Quick Response System X (QRS-X) CVT,
high airflow with strategically positioned CVT air intake and
exhaust, L / H / N / R / P
Drive Train Lockable front differential with exclusive
Smart-Lok* technology
True 4 modes traction system:
2WD / 4WD with front diff. lock / 4WD MUD / 4WD TRAIL
Power Steering High-torque Tri-Mode Dynamic Power Steering (DPS™)
SUSPENSIONS
Front Suspension Double arched A-arm with sway bar /
22 in. (55.9 cm) suspension travel
Trophy Truck inspired arms
Front Shocks FOX†
2.5 PODIUM Piggyback with QS3†
compression adjustment
Rear Suspension 4-link Torsional Trailing Arm X (TTX) with sway bar and
arched lower links / 22 in. (55.9 cm) suspension travel
Rear Shocks FOX†
2.5 PODIUM Piggyback with QS3†
compression
adjustment and bottom-out control
TIRES & WHEELS
Front / Rear Tires ITP Cryptid 30 x 9 / 11 x 14 in.
Wheels 14 in. cast-aluminum beadlock
BRAKES
Front Dual 262 mm disc brakes with hydraulic twin-piston calipers
Rear Dual 248 mm disc brakes with hydraulic twin-piston calipers
